2019 Yamaha GRIZZLY EPS SE

2019 Yamaha GRIZZLY EPS SE
Backcountry Blue w/Aluminum Wheels
MSRP: $10,499.00
Manufacturer: Yamaha
Condition: New

Description

  • Big Bore Engine Designed For Aggressive Trail Riding
    Rebuilt for 2019, the Grizzly® EPS SE brings even more riding excitement without losing an ounce of comfort, thanks to its new 700-class engine with improved midrange power and smooth-running motor mounts.
  • High-Performance Ultramatic® Transmission
    Yamaha’s class-leading transmission combines immediate response with advanced features like natural, all-wheel engine braking for control on confidence. And, of course, the Ultramatic is proven to be the most durable ATV transmission on the market.
  • Trail-Ready Chassis
    With plenty of ground clearance and adjustable suspension, the Grizzly EPS SE tackles rough terrain with ease. Beyond the long-travel shocks, wide-arc A-arms and full-body skid plates ensure the Grizzly EPS SE is ready to keep going when you are.
  • Yamaha’s Exclusive On-Command® 4WD
    Unlike so many 4WD ATVs systems on the market that put a computer in charge, the Yamaha On-Command system keeps the rider in charge, with selectable 2WD, 4WD limited-slip, and 4WD with diff. lock modes to ensure the Grizzly EPS SE delivers power consistently as required.
  • Class-Leading Power Steering
    Reduced fatigue, excellent control and trail feel all come standard with Grizzly’s best in industry speed-sensitive Electric Power Steering (EPS).

Specifications

Engine

Engine Type
686cc liquid-cooled SOHC 4-stroke
Bore x Stroke
102.0mm x 84.0mm
Compression Ratio
10.0:1
Fuel Delivery
Yamaha Fuel Injection (YFI), 44mm
Transmission
Ultramatic V-belt with all-wheel engine braking; H, L, N, R, P
Final Drive
On-Command 3-way locking differential; 2WD, 4WD, locked 4WD; shaft


Chassis

Suspension / Front
Independent double wishbone; 5-way preload adjustment, 7.6-in travel
Suspension / Rear
Independent double wishbone with anti-sway bar; 5-way preload adjustment, 9.1-in travel
Brakes / Front
Dual hydraulic disc
Brakes / Rear
Dual hydraulic disc
Tires / Front
AT27 x 10-14 Maxxis® Zilla® MU01
Tires / Rear
AT27 x 10-14 Maxxis® Zilla® MU01


Dimensions

L x W x H
81.5 in x 49.2 in x 50.0 in
Seat Height
36.6 in
Wheelbase
49.2 in
Turning Radius
146.0 in
Maximum Ground Clearance
11.8 in
Fuel Capacity
4.8 gal
Wet Weight
780 lb
Rack Capacity
110 lb (front) / 198 lb (rear)
Towing Capacity
1322 lb


Other

Warranty
6 Month (Limited Factory Warranty)


Features

Top Features

  • Big Bore Engine Designed For Aggressive Trail Riding
    Rebuilt for 2019, the Grizzly® EPS SE brings even more riding excitement without losing an ounce of comfort, thanks to its new 700-class engine with improved midrange power and smooth-running motor mounts.
  • High-Performance Ultramatic® Transmission
    Yamaha’s class-leading transmission combines immediate response with advanced features like natural, all-wheel engine braking for control on confidence. And, of course, the Ultramatic is proven to be the most durable ATV transmission on the market.
  • Trail-Ready Chassis
    With plenty of ground clearance and adjustable suspension, the Grizzly EPS SE tackles rough terrain with ease. Beyond the long-travel shocks, wide-arc A-arms and full-body skid plates ensure the Grizzly EPS SE is ready to keep going when you are.
  • Yamaha’s Exclusive On-Command® 4WD
    Unlike so many 4WD ATVs systems on the market that put a computer in charge, the Yamaha On-Command system keeps the rider in charge, with selectable 2WD, 4WD limited-slip, and 4WD with diff. lock modes to ensure the Grizzly EPS SE delivers power consistently as required.
  • Class-Leading Power Steering
    Reduced fatigue, excellent control and trail feel all come standard with Grizzly’s best in industry speed-sensitive Electric Power Steering (EPS).

New for 2019

  • New 700-Class Engine
    For 2019, Yamaha’s engineers wanted to boost the performance of the big bore Grizzly EPS SE even further, with more useable power throughout the rev range. At the same time, the new motor features redesigned engine mounts, so despite the increase in performance, it runs even smoother than before.
  • New Special Edition Model
    The new 2019 Grizzly EPS SE takes trail performance to the next level with stylish alloy rims mounting oversize 27-inch tires. Tackle mud, slippery hills and rocky slopes with confidence.

Capability

  • High-Performance Ultramatic® Transmission
    Grizzly EPS SE's Ultramatic® transmission features a gated shifter, dual-range (Hi/Lo) drive plus reverse gear, and is the most advanced—and durable—CVT drive system available. An automatic centrifugal clutch maintains constant belt tension for reduced belt wear and a sprag clutch delivers natural all-wheel engine braking.
  • New Engine Built to Excite
    For the trail rider looking for excitement in every ride, the ideal engine should balance big bore power with a strong midrange that gives immediate response. The Grizzly EPS SE features a potent new 700-class engine for 2019 with optimized torque, power delivery and engine character for aggressive recreational riding.
  • Yamaha’s Exclusive On-Command 4WD
    The three-position On-Command® 4WD system lets you switch between 2WD, limited-slip 4WD and a fully locked differential 4WD all with the simple push of a button. An override button allows engine to reach maximum rpm in full diff lock mode, and a straight driveshaft layout eliminates U-joints for reduced friction, noise, vibration, and maintenance.
  • High-Mounted Air Intake
    Tackle mud and water thanks to the Grizzly EPS SE’s high-mounted air intake layout. The design increases power and torque while providing additional room for on-board storage and easy, tool-less servicing of the foam air filter.
  • Stainless Steel Exhaust
    To maintain clean-running performance for years, the Grizzly EPS SE uses a stainless steel exhaust system and features a screen-type spark arrestor for great power with minimum noise output.
  • High-Capacity Radiator
    Slow-speed technical riding can place a lot of thermal demands on a liquid-cooled motor, so the Grizzly features a high-capacity radiator with fan assist that delivers plenty of air flow for maximum cooling efficiency—and it’s positioned high in the frame for optimal protection.
  • Drive System Air Intake
    Specially designed, high-mounted drive system air intake helps reduce drive system temperatures and assists in keeping water and debris from entering the drive case.
  • New 27-inch SE Tire Package
    For deep mud, scree slopes and any other poor traction terrain out there, the Grizzle EPS SE comes ready to climb with big 27-inch Maxxis® Zilla® tires mounted on strong and lightweight alloy rims. The new Zilla® tires use dual-compound sidewalls and an extra-tough carcass construction to handle anything you can throw at them.
  • Four-Wheel Hydraulic Disc Brakes
    Powerful and consistent braking comes standard on every Grizzly EPS SE thanks to four-wheel hydraulic disc brakes with unmatched braking feel.
  • Generous Ground Clearance
    To handle nearly any terrain with ease, the Grizzly EPS SE offers an impressive 11.3 inches of maximum ground clearance and full-length composite skid plates, for maximum underbelly protection.

Comfort

  • Independent Double Wishbone Front and Rear Suspension
    Independent double wishbone suspension, with 7.6” of front wheel travel and 9.1” at the rear, provides excellent rider comfort even on the toughest trails, thanks to nitrogen-charged shocks with 5-way adjustable preload.
  • Class-Leading Power Steering
    Minimize fatigue and attack every corner with Yamaha’s Electric Power Steering (EPS), the industry’s best balance of electric steering assist and positive trail feedback.
  • Underseat Fuel Tank
    An optimized 4.76-gallon fuel tank is located under the seat for excellent mass centralization and handling.
  • Plush Saddle
    A long, plush seat improves rider comfort for extended days exploring every trail, with plenty of room for the rider to move during aggressive riding.
  • New Instrument Package
    For 2019, the Grizzly EPS SE receives a new instrument cluster with larger all-LCD readouts for visibility.

Confidence

  • Aggressive and Durable Styling
    Rugged composite front bumper resists scratching and won’t rust, while injection-molded fenders and CV joint guards protect against rock and debris damage.
  • LED Headlights and Taillight
    LED technology uses less power, creates brighter, sharper illumination, and offers lifetime durability. A handlebar-mounted halogen work light provides additional illumination that moves with rider input for excellent visibility.
  • Ready for Accessories
    The Grizzly EPS SE was engineered in concert with a range of accessories for perfect fit and function, for nearly every type of ride you can find. With a standard 12V power point, you can keep devices charged, too.
  • Extensive Cargo Capacity
    Rugged, large-diameter steel cargo racks with durable wrinkle paint finish can pack a total of 308 pounds combined (110 lbs. front, 198 lbs. rear). Three on-board storage compartments keep things secure.
  • Work-Ready Tow Capacity
    Center-mounted, heavy-duty two-inch receiver comes standard on Grizzly and can tow more than 1300 pounds.
  • Built Real World Tough™, Assembled in the USA
    As with other Yamaha ATVs and Side-by-Sides, the Grizzly EPS SE is assembled in the USA to meet Yamaha’s exacting standards for durability and reliability.

All inventory listed is subject to availability and prior sale. Manufacturer's Suggested Retail Price (MSRP) if shown for a vehicle excludes set-up, freight, taxes, title, licensing or other dealer charges, and is subject to change. Individual prices may vary. Please request a quote for specific pricing.
